Description
F17724102200 VISHAY CAP FILM 0.1UF 20% 630VDC RADIAL RoHS
This interference suppression F17724102200 film capacitor from Vishay is ideal for voltage smoothing, and would make any filter or audio based design better for the smoothest signal. It can withstand a voltage of 310 VAC. This part has a maximum operating temperature of 110 °C. This part has a lead diameter of 0.6 mm and a pitch of 15 mm. The F17724102200 part has a radial termination style. Its capacitance value is 0.1uF. It has a tolerance of 20%. This product is 17.5(Max) mm long, 12(Max) mm tall and 6(Max) mm deep.
Specifications
Manufacturer: Vishay
Product Category: Film Capacitors
RoHS: RoHS Compliant
Termination Style: Radial
Product: Suppression Film Capacitors
Dielectric: Polyester
Capacitance: 0.1 uF
Voltage Rating AC: 275 V
Voltage Rating DC: 630 VDC
Tolerance: 20 %
Lead Spacing: 15 mm
Minimum Operating Temperature: – 40 C
Maximum Operating Temperature: + 100 C
Length: 17.9 mm
Width: 12 mm
Height: 6 mm
Series: F1772-x
Brand: Vishay / Roederstein
Lead Diameter: 0.8 mm
Lead Style: Straight
Packaging: Bulk
Qualification: Commercial
Factory Pack Quantity: 600
Type: AC-Capacitors, Suppression Capacitors Class X2 AC 275 V (MKT)
Manufacturer Part Number: F17724102200
Manufacturer: Vishay
