Description
Specifications
2.54mm Female Header,Dual Row
F185-12XXXXXMYX1 F185-12XXXXXZYX1
No.Of Pins Per Row: 02~40P
Contact Plating: Full Of Gold Semi-Gold
A0=0.8u” B0=0.8U”
A9=30u” B9=30U”
S1=Ordinary Tin Plated
S2=Matte Tin Plated
S3=Tin-plated High-temperature
Insulator Material:
A:PBT
B:PA6T
C:PA9T
D:LCP
Packing
A:PE Bag
B:Tape & Reel
C:Tube
D:Tube+CAP
E:Tray
F 1 8 5 – 1 2 X X X X X X Y X 1
Contact Shape:
S:Straight
R:Right Angle
M:SMT
Z:90 SMT
(Remark)
(Material):PA9T /LCP+30%G.F UL94V-0,
Housing:PA9T/LCP+30%G.F UL94V-0,Color:Black
Contact:Phosphor Bronze
2.(characteristics):
Rating Current:3.00AMP
20mO Max
Contact Resistance:20mO Max
1000MO Min
Insulating Resistance:1000 MO Min
:AC 1000V
Withstanding Voltage:AC 1000V/Minute
-40C to+105C
Temperture Range: -40C to+105C
Manufacturer:Electronic Components
Datasheet:F185-12.pdf
