Fairchild – FSC 74LS374DW Octal D-Type Edge Triggered Flip-Flops with 3-State Outputs 20-SOIC 0 to 70 SMD OCTAL D-TYPE FLIP-FLOP
Logic Family LS
Logic Function D Type
Output Type 3 State
Triggering Type Positive Edge
Mounting Type Surface Mount
Package Type SOIC
Product Category: Flip Flops
Number of Circuits: 8
Logic Family: LS
Logic Type: Transparent D-Type Latch
Polarity: Non-Inverting
Input Type: TTL
Output Type: TTL
Low Level Output Current: 24 mA
Supply Voltage – Max: 5.25 V
These 8-bit registers feature 3-state outputs designed specifically for driving highly capacitive or relatively low-impedance loads. The high-impedance 3-state and increased high-logic-level drive provide these registers with the capability of being connected directly to and driving the bus lines in a bus-organized system without need for interface or pullup components. These devices are particularly attractive for implementing buffer registers, I/O ports, bidirectional bus drivers, and working registers.
Manufacturer Part Number: 74LS374DWD
Fairchild Semiconductor
