Description
FAN5702UC15X Fairchild / On Semiconductor LED Driver, Input Voltage Min:2.7V, Input Voltage Max:5.5V, Output Voltage Max:-, Output Current Max:20Ma, Switching Frequency Typ:1.2Mhz, Ic Mounting:Surface Mount, ROHS
The FAN5702 is a highly integrated and configurable charge-pump- based multi-LED driver. The device can drive up to six LEDs in parallel with a total output current of 180 mA. Regulated internal current sinks deliver excellent current and brightness matching to all LEDs.
Product Category: LED Lighting Driver ICs
Number of Outputs: 6 Output
Topology: Charge Pump
Output Current: 15 mA
Package / Case: WLCSP-16
Supply Voltage – Max: 5.5 V
Supply Voltage – Min: 2.7 V
Operating Frequency: 1.2 MHz
Output Voltage: Adjustable
Series: FAN5702
Minimum Operating Temperature: – 40 C
Maximum Operating Temperature: + 85 C
Features: I2C Control
Packaging: Reel
Packaging: Cut Tape
Brand: onsemi
High Level Output Current: 180 mA
Input Voltage: 2.7 V to 5.5 V
Mounting Style: SMD/SMT
Number of Channels: 6 Channel
Product: LED Drivers
Product Type: LED Lighting Drivers
Subcategory: Driver ICs
Supply Current – Max: 4.4 mA
Type: Charge Pump
Unit Weight: 0.001658 oz
