Description
FV1.25-M3(LF) JST Ring Tongue JST, FV Insulated Terminal, M3 (#6 -> #12) Stud Size, 0.25mm2 to 1.65mm2 Wire Size, Red RoHS
Attribute: Value
Insulation: Insulated
Insulation Material: Vinyl
Inner Ring Diameter: 3.7mm
Outer Ring Diameter: 6.6mm
Minimum Wire Size mm2: 0.25mm2
Maximum Wire Size mm2: 1.65mm2
Maximum Wire Size AWG: 16AWG
Minimum Wire Size AWG: 22AWG
Stud Size: M3 (#6 -> #12)
Colour: Red
Thickness: 0.8mm
Overall Length: 18.6mm
Manufacturer: JST
MFG Part #: FV1.25-M3(LF)
