Description
Technical data
Category Tamper-proof pushbutton
Features planar
Casing/button colour Stainless steel
Functions momentary
Lighting type circular lighting
Light colour Red
Bulb type LED
Key type Flush
Switch position 1 x Off/(On)
Contact type 1 maker
Material Stainless steel
Contact material Silver alloy
Connection Soldering
Switching voltage 48 Vdc
Switching current (max.) 2 A
IF 20 mA
Min. temperature -20 C
UF 1.7 V
Max. temperature +55 C
Recess diameter 16 mm
Protection type IP65
Content 1 pc(s)
Type GQ16F-10E/J/R/12V
Board thickness (max.) 10 mm
Manufacturer Part Number: GQ16F-10DT/12V/R
Manufacturer: Electronic Components
