HDL36125 Schneider / Square D Molded Case Circuit Breaker Feed-Thru – 125Amp 600Volt 3 Pole
PowerPacT H-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT H-Frame circuit breakers are available with either thermal magnetic or Micrologic electronic trip protection units. This PowerPacT H-Frame circuit breaker provides thermal magnetic circuit protection with a breaking capacity of 14kA at 600VAC. All PowerPacT H-Frame circuit breakers are equipped with dual-break rotating contacts that reduce the amount of peak current during a short circuit fault. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT H circuit breakers are available in 2 and 3-pole unit mount and I-Line constructions. This breaker has lugs on both the line and load sides. This PowerPacT H, 125A, 3 pole, circuit breaker has a breaking capacity of 14kA at 600VAC. This circuit breaker has a continuous current rating of 80%. PowerPacT H circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.
ROBUST CIRCUIT PROTECTION: PowerPacT H-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits; Dual-break rotating contacts that reduce the amount of peak current during a short circuit fault
THERMAL MAGENTIC PROTECTION: Thermal-magnetic protection provides thermal protection against overload and instantaneous protection against short circuits for general-purpose applications
MANUAL TRIP FUNCTION: PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker; This model features a front facing semi transparent cover for quick visual identification
LUGS: This breaker has lugs on both the line and load sides for easy cable connections; Snap-in terminal makes converting between busbar and lug options easy
SPECIFICATIONS AND CERTIFICATIONS: This PowerPacT H-Frame 125A 3 pole circuit breaker has a breaking capacity of 14kA at 600VAC; Continuous current rating – 80%; Complies to UL, CSA, NOM, and IEC standards; CE marked; Covered by 18-Month Warranty
Specifications
Amperage
125 Amp
Applications
PROVIDES OVERLOAD AND SHORT CIRCUIT PROTECTION
Control Type
Toggle
Frame
H-FRAME
Interrupt Rating
14, 18, 20, 25 kAIC
Line Rated Current
125-125 A
Mounting Type
Unit Mount
Net Weight
2.2 kg
Number of Poles
3 Pole
Operating Temperature
-13F AND 158F (-25 C AND +70 C)
Range
PowerPact
Standard
CSA,IEC 60947-2,NEMA,NOM-003-SCFI-2000,UL
Storage Temperature
-50-85 degrees C
Strip Length
16 mm
Tc Connection
LINE: LUG – LOAD: LUG
Trip Point
1700-1700 A
Trip Range
HOLD: 900A – TRIP: 1700A
Trip Type
thermal-magnetic
Type
circuit breaker
Voltage
250 Volt
Manufacturer Information
Brand
Square D
Sub Brand
POWERPACT
General Product Info
12-Digit UPC
785901955849
Color
Black
MDM Pkg GTiN
00785901955849
Product UPC
78590195584
Weight
2.2 kg
Dimensions
Depth
3.39 in
Height
6.42 in
Length
16 mm
Warranty Length
18 mth
Width
4.09 in
