Mersin HelioProtection Z1064508 – HP15NH1XLGPV63 gPV Solar Fuse 63 A NH-fuse-links gPV 1500VDC plain blade
Size: 1XL
Rated current: 63A
Power dissipation: 25W 10.2W
Weight: 0.7kg
Item number: Z1064508
Catalog number: HP15NH1XLGPV63
Manufacturer: Mersen
Key features & benefits
All photovoltaic applications
- Inverter DC input protection
- Re-combiner applications (sub combiner, array combiner, master combiner)
Mersen HP15NH photovoltaic (PV) fuse serie was engineered and designed specifically for the protection of photovoltaic systems. Helio-Protection® HP15NH fuse links are designed for the protection of cables in a PV group of chains when a short circuit occurs in a panel (main fuse category). This HelioProtection® main fuse range enlarges our PV fuse links offering on 1XL/2XL/3L sizes having a worldwide acceptance. They are of the gPV type and comply with both IEC 60269-6 and UL 2579 PV standards. They are available with plain blades, bolted blades for direct mounting with and without striker.
