Description
Mersin HelioProtection X1048682 – HP15NH3LGPV315B gPV Solar Fuse 315 A NH-fuse-links gPV 1500VDC direct mounting Fuse link DC1500V 315A sfu – Knife blade fuse Other 315A HP15NH3LGPV315B – Mersen – X1048682 – 3605340578034: Safety device size according to IEC 60269 3L, Voltage DC, Rated current 315 A, Rated voltage DC 1500 V, Design indicator without, Insulated metal handle tabs (IMGL) no, Power loss at rated current 57 W
Size: 3L
Rated current: 315A
Power dissipation: 57W 23W
Weight: 1.66kg
Item number: X1048682
Catalog number: HP15NH3LGPV315B
Manufacturer: Mersen
Key features & benefits
All photovoltaic applications
- Inverter DC input protection
- Re-combiner applications (sub combiner, array combiner, master combiner)
Datasheet: Datasheets
Mersen HP15NH photovoltaic (PV) fuse serie was engineered and designed specifically for the protection of photovoltaic systems. Helio-Protection® HP15NH fuse links are designed for the protection of cables in a PV group of chains when a short circuit occurs in a panel (main fuse category). This HelioProtection® main fuse range enlarges our PV fuse links offering on 1XL/2XL/3L sizes having a worldwide acceptance. They are of the gPV type and comply with both IEC 60269-6 and UL 2579 PV standards. They are available with plain blades, bolted blades for direct mounting with and without striker.
