IMSA-9615S-10C-PP-A IRISO FFC/FPC Connector 10 Position DIP

Description

IRISO IMSA-9615S-10C-PP-A Connector FFC-FPC 50V 500mA 1.00 mm pitch, NON-ZIF, SMT type FPC / FFC connector, straight (single-sided contact) and right angle (upper contact) types are available to improve card prying contact reliability (R contact shape), straight, right angle Prepare a type. Achieves a light insertion feeling and strong removal force. Lead free / RoHS: Compliant

Product Details
Floating: No
Connection Orientation: Right Angle/Horizontal
Pitch: 1.0
Pin Count: 10
Plating:
Mount: DIP/Through-hole
Boss Type: Forming
Vacuum Tape Included: No
Terminal Material: Phosphor Bronze
Part Height: 4.0
Base
Base Number: C
Mold Material: PBT
Packaging Type: Tape
Environmental
Beryllium & Halogen Free: No
Advanced
Current Rating: 0.5A
High Speed: No
