Description
ISOCOM 4N35XG, OPTOCOUPLER PHOTOTRANSISTOR, 5300VRMS, DIP 6
Mfr Package Description PLASTIC, DIP-6
REACH Compliant Yes
EU RoHS Compliant Yes
Status Active
Optoelectronic Device Type TRANSISTOR OUTPUT OPTOCOUPLER
Coll-emtr Bkdn Voltage-Min 30 V
Configuration SINGLE
Current Transfer Ratio-Nom 100 %
Current Transfer Ratio-Min 100 %
Dark Current-Max 50 nA
Forward Current-Max 0.0600 A
Forward Voltage-Max 1.5 V
Isolation Voltage-Max 5300 V
Mounting Feature THROUGH HOLE MOUNT
Number of Elements 1
Operating Temperature-Min -55 Cel
Operating Temperature-Max 100 Cel
Power Dissipation-Max 0.1600 W
Response Time-Max 1.00E-5 s
Sub Category Optocoupler – Transistor Outputs
Terminal Finish NOT SPECIFIED
Additional Feature VDE APPROVED, UL RECOGNIZED
1 CHANNEL TRANSISTOR OUTPUT OPTOCOUPLER
The 4N35, 4N36, 4N37
series of optically
coupled isolators consist of infrared light
emitting diode and NPN silicon photo transistor
in a standard 6 pin dual in line plastic package.
Manufacturer:Isocom
Datasheet:Isocom/4N35XG.pdf
