Description
The IT68051 is a dual-port HDMI2.0b receiver which supports 6.0Gbps/channel capability and up to 18Gb/s bandwidth for each port. The port-0 also can operate in both HDMI2.0b and MHL2.2 dual mode, it is fully compatible with MHL2.2, HDMI 1.4b/HDMI2.0b, HDCP 1.4/HDCP2.2 and also backward compatible to DVI 1.0 specifications. The IT68051 with its Deep Color capability (up to 36-bit) ensures robust reception of high-quality uncompressed video content, along with state-of-the-art uncompressed and compressed digital audio content such as DTS-HD and Dolby TrueHD in digital televisions and projectors. The IT68051 also supports all the primary 3D formats which are compliant with the HDMI 2.0 3D specification.
Dual port HDMI2.0b Receiver
Support 2 HDMI1.4/HDMI2.0b (18Gb/s) input ports (port-0, port-1)
Support HDMI1.4, HDMI2.0b/MHL2.2 dual mode on input port-0
Compliant with MHL2.2, HDMI1.4b, HDMI 2.0, HDCP1.4, HDCP 2.2 and DVI 1.0 specifications
Supporting link speeds of up to 6.0Gbps (link clock rate of 600MHz) for 4K2K@60hz or 1920×1200@120hz with deep color solution, and up to 1080p@60hz on MHL packed pixel mode
Manufacturer Part Number: IT68051
Manufacturer: Electronic Components
