Description
LAN8710AI-EZK-ABC Microchip 10/100 Base-T/TX Ethernet Transceiver with MII/RMII Interface1.2V 32-QFN Tray RoHS
Specifications
Manufacturer: Microchip
Product Category: Ethernet ICs
Mounting Style: SMD/SMT
Package / Case: SQFN-32
Product: Ethernet Transceivers
Standard: 10BASE-T, 100BASE-TX
Number of Transceivers: 1 Transceiver
Data Rate: 10 Mb/s, 100 Mb/s
Interface Type: MII, RMII, SMI
Operating Supply Voltage: 3.3 V
Minimum Operating Temperature: – 40 C
Maximum Operating Temperature: + 85 C
Series: LAN8710A
Packaging: Tray
Brand: Microchip Technology
Supply Current – Max: 24.1 mA, 54 mA
Duplex: Full Duplex, Half Duplex
Moisture Sensitive: Yes
Pd – Power Dissipation: 79.5 mW, 176 mW
Product Type: Ethernet ICs
Factory Pack Quantity: 490
Subcategory: Communication & Networking ICs
Supply Voltage – Max: 3.6 V
Supply Voltage – Min: 1.08 V
Unit Weight: 0.014462 oz
Microchip’s LAN8710A/LAN8710Ai are high-performance, small-footprint, low-power 10BASE-T/100BASE-TX transceivers specifically designed for today’s consumer electronics, industrial and enterprise applications. The LAN8710A/LAN8710Ai are the industry’s smallest footprint solution with up to 40% lower power consumption than existing Microchip transceivers. The LAN8710A/LAN8710Ai have an integrated voltage regulator and ESD protection components to help reduce Bill of Material (BOM) costs.
The LAN8710A/LAN8710Ai connect to the MAC layer using a variable voltage, digital standard MII or RMII interface, These devices support HP Auto-MDIX†, employ Microchip’s proprietary flexPWR technology and are available in both extended commercial (0° to 85°C) and industrial (-40° to 85°C) temperature range options.
Microchip’s complimentary and confidential LANCheck® online design review service is available for customers who have selected our products for their application design-in*.
†HP Auto-MDIX eliminates the need for special “crossover” cables when connecting LAN devices together.
Manufacturer:Microchip Technology
Datasheet:Microchip/00002164B.pdf
