Description
PANDUIT LCAS1-38H-E One-hole, flex lug, 1/0 AWG wire, 3/8 stud hole, 45° angle tongue. TERMINALS COPPER COMPRESSION LUG, 1 HOLE, #1 AWG, ROHS
Features
Color-coded barrels marked with PANDUIT and specified competitor die index numbers for proper crimp die selection
Inspection window to visually assure full conductor insertion
Tin-plated to inhibit corrosion
UL Listed and CSA Certified to 35 KV and teperature rated to 90C when crimped with PANDUIT and specified competitor crimping tools and dies
UL Listed and CSA Certified for wide wire range-taking capability when crimped with PANDUIT(TM) Uni-Die(TM) Dieless Crimping Tools
Tested by Telcordia – meets NEBS Level 3
American Bureau of Shipping Approved
Available with NEMA hole sizes and spacing
Material Tin-Plated Copper
Panduit Die Index Number P42
Barrel Type Standard Barrel Length with Inspection Window
Color Code Pink
Tongue Angle 45°
Wire Strip Length (mm) 19.1
Burndy Die Index Number 12
Conductor Material Copper
Product Type Tin-Plated Copper Compression Connectors – Lugs
Class G,H, I, K, M 1/0 AWG
Code Conductor Size #1/0 AWG
Diesel Locomotive 1/0 AWG
Tongue Thickness In. (mm) 0.13 (3.3)
Tongue Width In. (mm) 0.85 (21.6)
Wire Strip Length In. (mm) 3/4 (19.1)
T&B Die Index No. 42
American Bureau Shipping Approved Yes
CSA Certified C22.2 No. 65-13
Tested by Telcordia-Meets NEBS Level 3 No
Tin-Plating Meets ASTM B545-97, Class C 320µ-in (8 µm)
UL and CSA Temperature Rating 90°C
UL and CSA Voltage Rating 35kV
UL Listed 486A-486B File #E52164
Part Number Series LCAX
Technical Information Consult cable manufacturer for voltage stress relief instructions with applications greater than 2000 V
Barrel Style Standard
Sub Brand Pan-Lug
Manufacturer Part Number: LCAS1-38H-E
Manufacturer: Panduit
