Description
Ledtronics RBG280T3-5G-B LED =Right-Angled Modular LED Bargraphs, Interlocking System Provides Design Flexibility
Features:
Two, Three and Five LED Modules Snap Together to Form the Desired Configurations
Solid-State, High Shock / Vibration Resistant
Fast Turn On / Off Time
Long Life / 100,000+ Hours
Available in Standard and Special Colors
Available in White or Black Housings
Available in Custom Configurations
Options: For qualified applications and large quantity orders
Bi-Color / Tri-Color LEDs
Sunlight Visible LEDs
Low Current 2mA LEDs
Resistored LEDs
Surface Mount
White Housing
Applications:
Instrument Panels
PCB Mounted Status Panel Indicator
Indicators for Telecom / Data Comm / Networking Products
SPECS
Supplier: Ledtronics
Part No: RBG280T3-5G-B
RoHS: Unknown
HTS: 8541402000
ECCN: EAR99
Color: Yellow
Dimension: 12.7 x 8.26 x 10.16 mm
Family: RBG280T3-5G
Intensity: 7.6 mcd
LED Material: N/A
Lens Appearance: Diffused
Mounting: Through Hole
Number of LEDs: 5
Peak Wavelength: 585 nm
Pin Count: 5
Type: Uni-Color
Viewing Angle: 125 °
Manufacturer:Ledtronics
Datasheet:Ledtronics/RBG280T3.pdf
