Description
Legrand 403395 Circuit breaker; 400VAC; Inom: 2A; Poles: 3, Curve B; for DIN rail mounting
Legrand TX3 miniature circuit breaker according to EN 60898-1, VDE 0641-11, EN 60947-2, 3-pole, B characteristic, rated current In 2 A, rated breaking capacity Icn 6 kA according to EN 60898-1, rated voltage Un 400 VAC, rated frequency 50/60 Hz, energy limitation class 3, mounting on DIN rail according to EN 60715 using a snap-in fastening, clear information on the front of each device, clear red/green switch position indicator on the switch lever, with labeling window, with anti-misplacement protection for safe insertion of the conductor into the elevator terminal, and the possibility of attaching auxiliary devices. Miniature circuit breakers with B characteristic are primarily intended for line protection in lighting and socket circuits.
Specifications
Circuit breaker type
Miniature circuit breaker
Mounting type
Top-hat rail
number of poles
3
Length
77.80 mm
Width
53.10 mm
General information
Item number
25192663
Manufacturer
Legrand
Category
Residual-current device
Manufacturer No.
403395
Release date
24.10.2022
Circuit Breaker Features
Circuit breaker type
Miniature circuit breaker
Mounting type
Top-hat rail
number of poles
3
Tripping characteristic
B
Rated voltage
400 V
voltage type
AC
Insulation voltage (Ui)
500 V
Protection type (IP code)
IP20
Origin
Country of origin
France, Poland
Sustainability
Manufacturer commitment
RE100
Scope of delivery
Items per sales unit
1 pcs.
Product dimensions
Length
77.80 mm
Width
53.10 mm
Height
88 mm
