Description
LESD9L5.0T5G LRC Leshan Radio Co Ltd Diode TVS Dual Bi-Directional 5V 0.15W 2-Pin SOD-923 T/R RoHSThe is designed to protect voltage sensitive components from ESD. Excellent clamping capability, low leakage, and fast response time provide best in class protection on designs that are exposed to ESD. Because of its small size, it is suited for use in cellular phones, MP3 players, digital cameras and many other portable applications where board space is at a premium
Key Features
Small Body Outline Dimensions: 0.039? x 0.024?(1.0 mm x 0.60 mm) Low Body Height: 0.017? (0.43 mm) Max Stand-off Voltage: 3.3 V – 12 V Low Leakage Response Time is Typically < 1 ns ESD Rating of Class 3 (> 16 kV) per Human Body Model IEC61000-4-2 Level 4 ESD Protection We declare that the material of product compliance with RoHS requirements S- Prefix for Automotive and Other Applications Requiring Unique Site and Control Change Requirements; AEC-Q101 Qualified and PPAP Capable
Technical Attributes
Description Value Find similar Parts
ESD Protection Yes
Pin Count 2
Test Current 1 mA
Operating Temperature -55 to 150C
Package Dimensions 0.8 x 0.6 x 0.37 mm
Maximum Peak Pulse Current 9.4 A
Peak Pulse Power Dissipation 0.15 W
Maximum Reverse Leakage Current 0.5 uA
Minimum Breakdown Voltage 5.6 V
Direction Type Bi-Directional
Supplier Package SOD-923
Screening Level Extended Industrial
Configuration Dual
Mounting Surface Mount
Maximum Clamping Voltage 18.6 V
Maximum Reverse Stand-off Voltage 5 V
Maximum Processing Temperature 260C
Manufacturer:LRC
Datasheet:LESD9D5.0CT5G.pdf
