LH36125 Schneider Electric Molded- Thermal Magnetic Circuit Breaker 600V 125A DIN Rail Lever 3-Poles CSA, UL
The Square D LH36125 is a 3 Pole thermal magnetic molded case circuit breaker with a current rating of 125 Amps and a voltage rating of 600V. It has an interrupting rating of 65kA at 240VAC, 35kA at 480Y/277VAC, 25kA at 600Y/347VAC, 50kA at 250VDC, 20kA at 500VDC. The LH36125 has a I-Line style plug-in connection type and includes LI – long time and instantaneous functions.
Trip Setting: 625 TO 1250 AMPERE
Application: POWER DISTRIBUTION
Used On: CLASS 655/660/670/830 I-LINE[R] PANELBOARD/SWITCHBOARD
Approval: UL, CSA
Additional Information: FRAME TYPE L; SIZE 6 INCH W X 5.84 INCH D X 11 INCH H; MOUNTING TYPE PLUG ON; HIGH INTERRUPTING; WIRE SIZE (1) 1 AWG TO 600 KCMIL/(2) 1 AWG TO 250 KCMIL (ALUMINUM/COPPER)
Catalog Number: LH36125
Brand Name: I-LINE[R]
Model: LH
Type: MOLDED CASE, THERMAL MAGNETIC
Voltage Rating: 240/480/600 VAC AT 50/60 HZ, 480 VAC STAR/277 VAC AT 50/60 HZ, 600 VAC STAR/347 VAC AT 50/60 HZ (UL/CSA/NOM); 415 VAC AT 50/60 HZ (IEC), 250/500 VDC
Current Rating: 125 AMPERE
Number of Poles: 3
Interrupting Rating: 65 KILOAMPERE AT 240 VAC, 35 KILOAMPERE AT 480 VAC STAR/277 VAC OR 480 VAC, 25 KILOAMPERE AT 600 VAC STAR/347 VAC OR 600 VAC (UL/CSA/NOM); 20 KILOAMPERE AT 415 VAC (IEC), 50 KILOAMPERE AT 250 VDC, 20 KILOAMPERE AT 500 VDC
CATALOG DESCRIPTION: CIRCUIT BREAKER, LH, I-LINE, 125A, 3 POLE, 25KA, 600VAC, 50KA, 250VDC, PHASE ABC
Category: 3 Pole Non-Interchangeable Trip Thermal Magnetic Circuit Breakers
Full Technical Description: Thermal Magnetic Type; I-Line Panelboard and Switchboard Used on; UL, CSA Approval; Power Distribution Application; 600 Volt AC, 250 Volt DC Voltage Rating; 25 Kiloamp at 600 Volt AC Interrupting Rating; 125 Amp Current Rating; 3 Pole(S); 625 to 1250 Amp Trip Setting; POWERPACT[TM] Brand; Rohs/Reach Compliant; Overall Dimension 6 Inch Width X 4 Inch Depth X 12.5 Inch Height; Frame Type L; Terminal Type I-Line Connection Line Lug Load; Terminal Wire Size (1) 1 AWG to 600 kcmil (Copper/Aluminum), (2) 1 AWG to 250 kcmil (Copper/Aluminum); Phase Connection Type ABC; LH Model
Manufacturer: Square D Co.
Breaker Type: Thermal Magnetic
Mounting Type: DIN Rail
Number of Poles: 3
Illumination: 3
Actuator Type: Lever
VoltageRating: 600V AC
Current Rating: 125A (Amps)
Package: Box
