Description
LP-PS-1524 Omega Engineering Power Supplies 24Vdc 0.63A Low Profile DIN Rail
Universal AC Inputs/Full Range
Fits in 4″ Deep Enclosures
Isolation Class 2
Protections: Short Circuit/ Overload/Overvoltage
LED Indicator for Power On
% Full Load Burn-In Test
Install on 35 x 7.5 or 35 x 15 mm DIN Rail
Specs
Form Factor DIN rail
efficiency 80 to 89%
Isolation Resistance I/P-O/P
Inrush Current LP-PS-1524: Cold start 35A/115 Vac
Load Regulation 1%
Maximum Input Voltage 85 to 264 Vac
Maximum Operating Temperature 50C (122F)
Maximum Output Voltage 24 Vdc
Minimum Operating Temperature -20C (-4F)
Output Voltage Tolerance 1%
Overload Protection LP-PS-1524
Ripple and noise P-PS-1524
Withstand Voltage 3k Vac
Manufacturer:Electronic Components
Datasheet:Others/LP-PS.pdf
