M55302/55LA10H AIRBORN CONNECTOR SOCKET 10P .100 Centerline

Description

M55302/55LA10H AIRBORN CONNECTOR SOCKET 10P .100 Centerline
SPECIFICATIONS
Part #: M55302/55A10H
Part Category: Connectors
Manufacturer: Incon Incorporated
Description: 10 CONTACT(S), MALE, TWO PART BOARD CONNECTOR, SOLDER, PLUG
Status Active
Connector Type BOARD CONNECTOR
Body/Shell Style PLUG
Contact Finish – Mating GOLD OVER NICKEL (150)
Contact Finish – Termination GOLD OVER NICKEL (150)
Contact Gender MALE
DIN Conformance NO
Filter Feature NO
IEC Conformance NO
Manufacturer Series M55302/63

Part	Type	No. of Contacts	Mounting Hardware Options
Number	Description
0.100 Inch Spacing Between Contacts
M55302/55XXXXX	Plug, Socket Contacts, Straight	10, 14, 20,	L, M, S, H
		34, 26, 30,
		36, 40, 44,
		50, 54, 56,
		60, 66, 70
M55302/56XXXX	Receptacle, Pin Contacts	”	Jackset
M55302/57XXXX	Plug, Pin Contacts, Right Angle	“	X, Y, S, H
M55302/58XXXXX	Receptacle, Socket Contacts	“	X, Y, F, S, H
M55302/61XXXX	Plug, Pin contacts, Right Angle	“	Jackset
M55302/62XXXXX	Receptacle, Socket Contacts	“	L, M, S, H
M55302/63XXXX	Plug, Pin Contacts, Straight	“	L, M, S, F,
			H, X, Y
M55302/64XXXXX	Receptacle, Socket Contacts	“	F, X, Y
M55302/65XXXXX	Receptacle, Socket Contacts	“	X, Y, F, S, H
M55302/66XXXXX	Receptacle, Socket Contacts	“	L, M, S, F, H
M55302/59XXXX	Plug, Pin Contacts, Right Angle	90, 100, 120	X, Y, F, S, H
M55302/60XXXXX	Receptacle, Socket Contacts	90, 100, 120	X, Y, F, S, H
M55302/138XXXXX	Plug, Pin Contacts, Right Angle	160	X, Y, F, S, H
M55302/139XXXXX	Receptacle, Socket Contacts	160	X, Y, F, S, H
0.075 Inch Spacing Between Contacts
M55302/190LXXXX	Receptacle, Socket Contacts	100	X, Y, F, S,
			N, L, M
M55302/191XXXXX	Plug, Pin Contacts, Right Angle	100	X, Y, F, S,
			N, L, M
M55302/192LXXXX	Receptacle, Socket Contacts	122, 152	X, Y, F, S,
			N, L, M
M55302/193XXXXX	Plug, Pin Contacts, Right Angle	122, 152	X, Y, F, S,
			N, L, M

Socket Contact Type Code	Description
–	Normal Insertion Force(Not Available for /190 or /192)
L	Low Insertion Force


Table 1:  Contact Termination Options for M55302/57, /59, /61, /138, /191, /193

Terminal Type Code	Description
A	.109L Dip Terminal
B	.140L Dip Terminal
C	.172L Dip Terminal


Table 2:  Contact Termination Options for M55302/55, /56, /58, /60, /62, /63, /64

Terminal Type Code	Description
A	Solder Cup
B	.140L Dip Terminal
C	.172L Dip Terminal
F	.100 Flex Circuit Terminal(Not Applicable to /60, /63)


Table 3:  Contact Termination Options for M55302/190, /192

Terminal Type Code	Description
A	Solder Cup
B	.109L Dip Terminal
C	.140L Dip Terminal
D	.172L Dip Terminal
E	.093 Flex Circuit Terminal

Manufacturer:Electronic Components
Datasheet:Others/M55302.pdf
