Description
Motorola MC10H101ML Quad OR / NOR Logic Gate Surface Mount / SMD SOIC-16
Manufacturer: ON Semiconductor
Product Category: Logic Gates
Logic Function: MUX Gates
Logic Family: ECL
Number of Gates: 4 Gate
Number of Input Lines: 2 Input
Number of Output Lines: 2 Output
High Level Output Current: – 50 mA
Low Level Output Current: 50 mA
Propagation Delay Time: 1.6 ns
Supply Voltage – Max: – 5.46 V
Supply Voltage – Min: – 4.94 V
Maximum Operating Temperature: + 75 C
Mounting Style: SMD/SMT
Package / Case: SO EIAJ
Brand: ON Semiconductor
Logic Type: ECL
Minimum Operating Temperature: 0 C
The MC10H101M is a Quad 2-Input OR/NOR Gate with one input from each gate common to pin 12.
This is a functional/pinout duplication of the standard MECL 10K™ family part, with 100% improvement in propagation delay, and no increases in power-supply current.
Features:
Propagation Delay, 1.0 ns Typical
Power Dissipation 25 mW/Gate (same as MECL 10K)
Improved Noise Margin 150 mV (Over Operating Voltage and Temperature Range)
Voltage Compensated
MECL 10K Compatible
Pb-Free Packages are Available
Manufacturer Part Number: MC10H101ML
Manufacturer: Motorola
