Description
MC74HC73ADG ON Semiconductor Flip Flop JK-Type Neg-Edge 2-Element 14-Pin SOIC
Product Attributes
Categories Integrated Circuits (ICs)
Logic – Flip Flops
Manufacturer ON Semiconductor
Series 74HC
Packaging Tube
Function Reset
Type JK Type
Output Type Differential
Number of Elements 2
Number of Bits per Element 1
Clock Frequency 35MHz
Max Propagation Delay @ V, Max CL 21ns @ 6V, 50pF
Trigger Type Negative Edge
Current – Output High, Low 5.2mA, 5.2mA
Voltage – Supply 2 V ~ 6 V
Current – Quiescent (Iq) 4uA
Input Capacitance 10pF
Operating Temperature -55C ~ 125C (TA)
Mounting Type Surface Mount
Package / Case 14-SOIC (0.154″, 3.90mm Width)
Base Part Number 74HC73
Manufacturer:ON Semiconductor
Datasheet:on-semi/MC74HC73-D.PDF
