Description
MGM36600 Schneider Electric Circuit breaker, PowerPacT M, 600A, 3 pole, 600VAC, 18kA, lugs, ET 1.0, 80% Chassis Mount Lever 3-Poles CSA, UL
PowerPacT R-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT R-Frame circuit breakers have either a fixed long time electronic trip unit, ET 1.0I, or Micrologic trip units. Micrologic trip units can be interchanged in the field to allow for maximum flexibility; the basic electronic trip unit doesn’t have that interchangeability. This circuit breaker has a Micrologic Interchangeable Standard Trip with a 3.0 trip unit and an LI function. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT R circuit breakers are available in 2, 3, and 4-pole unit mount and I-Line construction (I-Line construction is available for 1000A and 1200A rated circuit breakers only). This unit has a busbar connection. This PowerPacT P, 2000A, 3 pole, circuit breaker has an interrupting rating of 18kA at 600VAC. This circuit breaker has a continuous current rating of 100%. PowerPacT R circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.
Amps 600 Amp
Breaker Interrupt Rating 1 65KA @ 240VAC
Breaker Interrupt Rating 2 35KA @ 480VAC
Breaker Interrupt Rating 3 18KA @ 600VAC
Breaker Line Side Term Method Lugs
Breaker Load Side Term Method Busbar (No Lugs)
Category Circuit Breakers, Square D by Schneider Electric
Circuit Breaker Type PowerPact Molded Case Circuit Breaker
Frame M-Frame
Height 12.1
Length 18.2
Manufacturer Square D by Schneider Electric
Maximum Interrupt Rating 18KA @ 600VAC
Number of Poles 3 Pole
Product Description 600Volt, 600Amp, 3-Pole
Trip Type Thermal Magnetic
UNSPSC 39121616
UPC 785902000000
Volts 600V
Width 10.5
Breaker Type: Solid State
Mounting Type: Chassis Mount
Number of Poles: 3
Illumination: 3
Actuator Type: Lever
VoltageRating: 600V AC
Current Rating: 600A (Amps)
Package: Box
