Description
MOLEX 71161-0402 Connector 4.20mm Mini-Fit® IDT Plug, Single Row, Gold (Au), 24 AWG Wire, 4 Circuits
Part Detail
Status Obsolete
Category IDT and Solder Connectors
Series 71690
Obsolete Date 2006/05/01
Product Name Mini-Fit® IDT
UPC 800755010428
Use With 71161-0401 Feed-Through Cover, 71161-0402 Feed-to Cover
Physical
Circuits (Loaded) 4
Circuits (maximum) 4
Color – Resin Natural
Durability (mating cycles max) 30
Flammability 94V-0
Gender Male
Glow-Wire Compliant No
Lock to Mating Part None
Material – Metal Phosphor Bronze
Material – Plating Mating Gold
Material – Plating Termination Tin
Material – Resin Polyester
Net Weight 3.973/g
Number of Rows 1
Packaging Type Bag
Panel Mount No
Pitch – Mating Interface 4.20mm
Plating min – Mating 0.381µm
Plating min – Termination 3.810µm
Stackable No
Temperature Range – Operating -40°C to +105°C
Termination Interface: Style IDT or Pierce
Wire Size AWG 24
Electrical
(Please review the Product Specification for specific details.)
Current – Maximum per Contact 7.0A
Voltage – Maximum 600V
Manufacturer Part Number: 71161-0402
Molex
