Description
Motorola – 4556BCL IC Dual binary to 1-of-4 decoder/demultiplexer 16P DIP
Package Description CERAMIC, DIP-16
Status Discontinued
Family 4000/14000/40000
JESD-30 Code R-GDIP-T16
JESD-609 Code e0
Load Capacitance (CL) 50 pF
Number of Functions 2
Number of Terminals 16
Operating Temperature-Min -55 Cel
Operating Temperature-Max 125 Cel
Output Polarity INVERTED
Package Body Material CERAMIC, GLASS-SEALED
Package Code DIP
Package Shape RECTANGULAR
Package Style IN-LINE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Propagation Delay (tpd) 440 ns
Qualification Status Not Qualified
Seated Height-Max 5.08 mm
Supply Voltage-Nom (Vsup) 5
Supply Voltage-Min (Vsup) 3 V
Supply Voltage-Max (Vsup) 18 V
Surface Mount NO
Technology CMOS
Temperature Grade MILITARY
Terminal Finish TIN LEAD
Terminal Form THROUGH-HOLE
Terminal Pitch 2.54 mm
Terminal Position DUAL
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Length 19.5 mm
Width 7.62 mm
Part #: MC14556BCL
Part Category: Logic ICs
Manufacturer: Motorola Solutions, Inc.
Description: 4000/14000/40000 SERIES, OTHER DECODER/DRIVER, INVERTED OUTPUT, CDIP16
Manufacturer Part Number: MC14556BCL
Manufacturer: Motorola
