Description
SAURO MSB12001 Screwclamp Terminal Block MSB Series, 12 poles, Cage Style Terminal Blocks 5.00 mm center, 17.5A@300V 16-30AWG MSB-12001 ROHS
No.of contacts
12
Contact pitch
5.00 mm
Number of rows
01
Contact style
FEMALE
Termin.style
THT
Contact plating
TIN
Orientation
STRAIGHT
Oper.temperatur
-40 TO 110 C
Current rating
17.5 A
Voltage rating
300 V
Series
MSB 001
Feature materia
PA
Feature funct.
ScrewClamp
Family
TERM.BLOCK
Automotive
NO
Leadfree Defin.
10
Packaging
BULK
Torque: 0.5 Nm
Strip length: 5mm
Spacing: 5.00mm
Positions: 12
Pin Dim.: .9mm x 0.5mm
PCB thickness: max 2.4mm
PCB holes: min 1.1mm
Operating Temp: -40C to +110C
Material Terminal: Copper Alloy, Tin-plated
Material Screw: M3, Copper Alloy, Ni plated
Material Housing: Polyamide 6,6 (UL 94V-O)
Material Clamp: Copper Alloy, NI plated
List Price@Factory Min: 2.14
Current: 13.5A @ 300V
Wire Range: 16-30 AWG
Country Of Origin:
Harmonized Code:
ECCN: EAR99
Mini-Euro PCB Mount, Screwless Terminal Blocks, Male/Female Pluggable, and Barrier/Tri-Barrier Style Terminal Blocks
DIN Rail terminal blocks, Pluggable type terminal blocks, European screwless type terminal blocks, Cage clamp type Terminal blocks, European P.C.B type terminal blocks, Dual & Tri Barrier Style terminal blocks
Manufacturer: Electronic Components
MFG Part #: MSB12001
