Description
P310-1108A0CS062A1 XYCON Connector Pin Header & Wire Housing 8 WAY SIL VERT PC TAIL P/HDR
Single 1.27mm pitch 9pin SMT type pin header connector
Specifications:
Product Name 1.27mm pitch 8pin SMT type pin header connector
Pitch 1.27mm
Detail Pin Header Connector
Housing PA9T/LCP + 30%G.F UL94V-0
Number of Pin 2~50pin
Insulator Height for Choice 1.0mm ,1.5mm ,1.6mm ,2.0mm ,2.5mm
Brand Name Yxcon
Contact Material Brass
Insulator Material PBT ,PA6T ,PA9T ,LCP ,PA66 ,PA46 ,PPS ,PA115(Halogen Free)
Rating Current 1.0AMP
Contact Resistance
20mO Max
Withstanding Voltage AC 500V/Minute
Insulating Resistance 1000mohm Min
Manufacturer:Electronic Components
Datasheet:P310-11XXA0CS062A1 (1).pdf
