Description
Panjit 2N7002DW Transistor MOSFET N-CH 60V 0.115A 6-Pin SC-70 T/R
The 2N7002 is a N-channel enhancement mode Field Effect Transistor produced using high cell density and DMOS technology. It minimizes on-state resistance while providing rugged, reliable and fast switching performance. It can be used in most applications requiring up to 400mA DC and can deliver pulsed currents up to 2A. Suitable for low-voltage, low-current applications, such as small servo motor control and power MOSFET gate drivers.
- High density cell design for extremely low RDS (ON)
- High saturation current capability
- Voltage controlled small signal switch
- Rugged and reliable
Applications
Power Management; Motor Drive & Control; Audio
FEATURES
• R
DS(ON), VGS@10V,IDS@500mA=5
• R
DS(ON), VGS@4.5V,IDS@75mA=7.5
• Advanced Trench Process Technology
• High Density Cell Design For Ultra Low On-Resistance
• Specially Designed for Battery Operated Systems, Solid-State Relays
Drivers : Relays, Displays, Lamps, Solenoids, Memories, etc
Manufacturer:Panjit
Datasheet:2N7002DW.pdf
