Description
Panjit 2N7002K Transistor MOSFET N-CH 60V 0.3A 3-Pin SOT-23 T/R , 60V N-Channel Enhancement Mode MOSFET – ESD Protected
Panjit
Case: SOT-23 Package
• Terminals : Solderable per MIL-STD-750,Method 2026
• Apporx. Weight: 0.0003 ounces, 0.0084 grams
• Marking : K72
The 2N7002 is a N-channel enhancement mode Field Effect Transistor produced using high cell density and DMOS technology. It minimizes on-state resistance while providing rugged, reliable and fast switching performance. It can be used in most applications requiring up to 400mA DC and can deliver pulsed currents up to 2A. Suitable for low-voltage, low-current applications, such as small servo motor control and power MOSFET gate drivers.
- High density cell design for extremely low RDS (ON)
- High saturation current capability
- Voltage controlled small signal switch
- Rugged and reliable
Applications
Power Management; Motor Drive & Control; Audio
Manufacturer:Panjit
Datasheet:2N7002K.pdf
