Description
Panjit 2N7002KDW MOSFET Mosfet Array 2 N-Channel (Dual) 60V 340mA 150mW Surface Mount SOT-363
Specifications
Manufacturer: Panjit
Product Category: MOSFET
Technology: Si
Mounting Style: SMD/SMT
Package / Case: SOT-363-6
Transistor Polarity: N-Channel
Number of Channels: 2 Channel
Vds – Drain-Source Breakdown Voltage: 60 V
Id – Continuous Drain Current: 250 mA
Rds On – Drain-Source Resistance: 4 Ohms
Vgs – Gate-Source Voltage: – 20 V, + 20 V
Vgs th – Gate-Source Threshold Voltage: 2.5 V
Qg – Gate Charge: 800 pC
Minimum Operating Temperature: – 55 C
Maximum Operating Temperature: + 150 C
Pd – Power Dissipation: 350 mW
Channel Mode: Enhancement
Qualification: AEC-Q101
Packaging: Reel
Brand: Panjit
Configuration: Dual
Fall Time: 23 ns
Product Type: MOSFET
Rise Time: 19 ns
Reel Size: 10000
Subcategory: MOSFETs
Transistor Type: 2 N-Channel
Typical Turn-Off Delay Time: 15 ns
Typical Turn-On Delay Time: 2.7 ns
Unit Weight: 0.000265 oz
FEATURES
• R DS(ON), VGS@10V,IDS@500mA=3
• RDS(ON), VGS@4.5V,IDS@200mA=4
• Advanced Trench Process Technology
• High Density Cell Design For Ultra Low On-Resistance
• Very Low Leakage Current In Off Condition
• Specially Designed for Battery Operated Systems, Solid-State Relays
Manufacturer:Panjit
Datasheet:2N7002KDW.pdf
