Description
Panjit BAT54AW-L Diode Schottky 30V 0.2A 3-Pin SOT-23 T/R , Surface Mount Schottky Barrier
Specifications
Product Category: Schottky Diodes & Rectifiers
Product: Schottky Diodes
Mounting Style: SMD/SMT
Package / Case: SOT-323-3
Configuration: Dual Cathode Common Anode
Technology: Si
If – Forward Current: 200 mA
Vrrm – Repetitive Reverse Voltage: 30 V
Vf – Forward Voltage: 800 mV
Ifsm – Forward Surge Current: 600 mA
Ir – Reverse Current: 2 uA
Minimum Operating Temperature: – 65 C
Maximum Operating Temperature: + 125 C
Packaging: Reel
Packaging: Cut Tape
Product Type: Schottky Diodes & Rectifiers
Subcategory: Diodes & Rectifiers
Type: Schottky Diode
FEATURES
• Low turn-on voltage
• Fast switching
• PN Junction Guard Ring for Transient and ESD Protection.
• Lead free in comply with EU RoHS 2011/65/EU directives.
• Green molding compound as per IEC61249 Std. . (Halogen Free)
Manufacturer:Panjit
Datasheet:BAT54AW-L.pdf
