Description
Permacel® P-222 Polyamide Film Electrical Tape, 0.5 in x 36 yd x 3.7 mil, Amber
P222 is a 3.75 mil, polyimide, film tape. It is engineered for heavy-duty, high temperature applications where 1-mil polyimide doesn’t provide adequate strength of physical protection. P222 is a versatile tape and is used as the primary insulation in high-performance, flexible wiring boards and heater blanket assemblies. When interlined with special treated cloth interliner, P222 can be die-cut into formable insulators.
Properties
| BACKING | 2-MIL Kapton® Polyimide Film |
|---|---|
| COLOR | Amber |
| INSULATION CLASS UL | 356°F -180°C |
| CERTIFICATIONS | UL-510 |
| GOVERNMENT SPECIFICATIONS | MIS 31631A Type II/ASTM D5213 TYPE 1, CLASS A (Replaces obsolete MIL-P-46112B) |
| IMPERIAL | METRIC | |
|---|---|---|
| TOTAL TAPE THICKNESS | 3.7 mils | 0.094 mm |
| TENSILE STRENGTH | 71 lbs/in | 124 N/10mm |
| ELONGATION | 90% | 90% |
| ADHESION TO STEEL | 26 oz/in | 2.8 N/10mm |
| DIELECTRIC STRENGTH | 13,000 volts | 13.0 kV |
Manufacturer:Electronic Components
Datasheet:Others/NDA_P-222_092013_EN.pdf
