Description
ATE Electronics THICK FILM POWER RESISTOR 22 kOhm 150W/70°C Up=1.5kVac SOT227 , Ui=2.5kVac TK+100ppm 0.5°C/W
Manufacturer: ATE
Nominal value :: 22.0 kΩ
Housing type: THT
Case: SOT-227
Component Type: Low Inductance
Specification: BP ± 100ppm
Nominal value tolerance ± 5%
RoHS Yes
Very good ratio Power / Volume.
Easy mounting and wiring with significant cost advantages.
Non inductive performance for high frequency applications.
One model for power up to 150W.
Suited to UL94-V0 application.
Manufacturer:Electronic Components
Datasheet:17-PR250.pdf
