Description
QCA-6174A-5-172BWLNSP Qualcomm Combo Wireless Modules WLAN+BT Chip 2400MHz/5000MHz 172-Pin WLNSP RoHS
Specifications
Construction
WLAN+BT
Style
Chip
WLAN Maximum Data Rate (Mbps)
620
WLAN Frequency Range (MHz)
2400(Typ)|5000(Typ)
BT Interface
UART/USB
BT Protocol Supported
Bluetooth v5.0(BLE)
WLAN Technology
IEEE 802.11ac
Mounting
Surface Mount
Package Height
0.57
Package Width
4.89
Package Length
6.02
PCB changed
172
Supplier Package
WLNSP
Pin Count
172
Designed to deliver a cost-effective Wi-Fi/Bluetooth combo solution, the Qualcomm® QCA6174A SoC (System-on-Chip) is an integrated, single-chip solution in a small form factor for mobile and consumer electronics applications.
QCA6174A supports high-speed Wi-Fi connectivity and enriched media experiences. It is optimized for energy efficiency, which is critical to extending the battery life of portable devices.
QCA6174A has integrated RF front-end and single-ended design for simpler and low-cost design. There are three variants available for QCA6174A:
QCA6174A-1: supports low power PCIe 2.1 (w/L1 substate) interface for WLAN and UART/PCM interface for Bluetooth
QCA6174A-3: supports low-power SDIO 3.0 interface for WLAN and UART/PCM interface for Bluetooth
QCA6174A-5: supports low power PCIe 2.1 (w/L1 substate) for WLAN and USB 1.1 interface for Bluetooth.
Datasheet: Qualcomm QCA6174A Wi-Fi/Bluetooth SoC
