Description
RSFR-135G(3X)-24/8-BLK HIGH SHRINK RATIO FLEXIBLE HEAT SHRINK TUBING RSFR-135G(3X) 24/8″ BLACK RoHS
High shrink ratio,flexible heat shrink tubing
Features
- Flexible
- High shrink ratio
- Flame retardant
- Resistant to common fluids and solvents
- Continuous Operating Temperature:-55? to 135?
- Shrink Temperature:120?
- RoHS compliant
- Meet SAE-AMS-DTL-23053/5
Dimensions
|
Size |
As supplied |
After Recovery(mm) |
Standard Package |
||
|
Inch |
mm |
Internal diameter Minr(mm) |
Internal diameter(mm) |
Wall thickness(mm) |
Spool Length m/spool |
|
1/16 |
1.5 |
1.5 |
0.5 |
0.45 |
200 |
|
1/8 |
3.0 |
3.0 |
1.0 |
0.55 |
200 |
|
3/16 |
4.5 |
4.5 |
1.0 |
0.60 |
100 |
|
1/4 |
6.0 |
6.0 |
2.0 |
0.65 |
100 |
|
3/8 |
9.0 |
9.0 |
3.0 |
0.75 |
50 |
|
1/2 |
12.0 |
12.0 |
4.0 |
0.75 |
50 |
|
5/8 |
15.0 |
15.0 |
5.0 |
0.80 |
50 |
|
3/4 |
18.0 |
18.0 |
6.0 |
0.85 |
50 |
|
1 |
24.0 |
24.0 |
8.0 |
1.00 |
25 |
|
1-1/4 |
30.0 |
30.0 |
10.0 |
1.15 |
1.22 |
|
1-1/2 |
39.0 |
39.0 |
13.0 |
1.50 |
1.22 |
|
2 |
50 |
50 |
16 |
2.50 |
1 |
|
|
60 |
60 |
20 |
2.60 |
1 |
|
|
70 |
70 |
23 |
2.60 |
1 |
|
3 |
80 |
80 |
26 |
2.60 |
1 |
|
|
90 |
90 |
30 |
2.60 |
1 |
|
4 |
100 |
100 |
33 |
2.60 |
1 |
Technical Data Physical
|
Property |
Test Method |
Typical Performance |
|
Tensile Strength |
ASTM D2671 |
10.4MPa |
|
Elongation(%) |
ASTM D2671 |
200% |
Electrical
|
Property |
Test Method |
Typical Performance |
|
Dielectric Strength |
IEC 243 |
≥15kv/mm |
|
Volume Resistivity |
IEC 93 |
≥1×1014Ω·? |
Manufacturer:Electronic Components
Datasheet:Others/20110929093522.pdf
