Description
RX680R BCM Advanced Research Motherboard 12/13/14th Gen. Intel® Core™ i9/i7/i5/i3 Processor, LGA 1700 Socket, Micro ATX Motherboard With Intel® R680E
LGA 1700 socket supports Intel® Core™ processors (Series 2), codenamed Bartlett Lake
LGA 1700 socket supports 12th/13th/14th Gen Intel® Core™ i 9/7/5/3 Processor, codenamed Alder Lake/Raptor Lake/Raptor Lake Refresh
Intel® Integrated UHD Graphic with Xe Architecture (CPU Dependent)
Intel® R680E PCH, x8 Gen4 DMI
4 x DIMM up to 128GB Max Dual Channel DDR5 4400 MHz with ECC Support
4 x DP++ (1.4a 4k) onboard support 4 Independent Displays
Gen 5/Gen 4/Gen 3 PCIe x16 and x4 slots, 3 x M.2 NVMe and CNVi
2 x Intel® Ethernet Controller I225 (2.5 GbE)
External USB: 6 x USB 3.2 Gen 2×1, 1 x USB 3.2 Gen 2×2 Type C
Internal USB: 1 x USB 3.2 Gen 2×1 Header (2 Ports), 4 x USB 2.0 Headers (8 Ports)
4 x SATA III RAID 0, 1, 5, 10
I²C, SMBus, GPIO, PS/2, LPT
Intel® AMT 16, Intel® ME 16
TPM 2.0
Supports Win 10/11, Linux
Specification
System Information
Processor
LGA 1700 Socket Supports 12/13/14th Generation Intel® Core™ i9/i7/i5/i3 Processors (Max. TDP at 65W)
Platform Controller Hub
Intel® R680E Chipset
System Memory
4 x 288 Pin DDR5 4400MHz Dual Channel U-DIMM Socket, Support up to 128GB (ECC Memory Support by CPU)
I/O Chipset
nuvoton NCT6126D
Watchdog Timer
H/W Reset, 5~255 Seconds/5~255 Minutes
BIOS
AMI uEFI BIOS, 256Mbit SPI Flash ROM
H/W Status Monitor
CPU Temperature Monitoring
Voltages Monitoring
CPU Fan Speed Control
TPM
infineon TPM 2.0
Board
Micro ATX
Expansion
Expansion
1 x Gen 5 PCIe x16
2 x Gen 4 PCIe x4 (x16 Physical Yellow)
1 x Gen 3 PCIe x4 Open Ended
1 x M.2 M-Key 2242/2280/22110 NVMe (Gen 4 PCIe x4 + SATA III)
1 x M.2 M-Key 2242/2280/22110 NVMe (Gen 3 PCIe x4 + SATA III)
1 x M.2 E-Key 2230 with CNVi Support (PCIe x1 + USB 2.0)
Display
Graphic Chipset
Intel® 12/13/14th Generation CPU Integrated
Spec. & Resolution
4 x DP (DP1.4a): Max: 4096 x 2304@60Hz
Multiple Display
Four Diaplay
LVDS
1 x LVDS Header
1 x eDP Header (Optional)
Audio
Audio Codec
Realtek ALC888S HD Audio Decoding Controller
Audio Interface
Line-out, Mic-in
Audio Amplifier
2 x 3W 8Ω Amplifier
Ethernet
LAN Chipset
2 x Intel® I225LM/I226LM 2.5 Gigabit Ethernet
LAN Port
2 x RJ45
Power Requirement
Power Mode
AT/ATX (Default Setting: ATX)
Software Support
OS
Windows 10, Windows 11, Linux
Certification
Certification Information
CE, FCC Class B, RoHS Compliant
I/O
USB
1 x USB 3.2 Gen2x2 Type C
6 x USB 3.2 Gen2x1
2 x USB 3.2 Gen2x1 by pin header
8 x USB 2.0 by pin header
COM Port
5 x RS-232 by pin header
1 x RS-232/422/485 by pin header
SATA
4 x SATA III
RAID
Support RAID 0, 1, 5, 10
DIO
1 x 8-bit GPIO
MIO
1 x PS/2 Header
1 x LPT Header
Mechanical & Environmental
Operating Temp.
0°C ~ 60°C (32°F ~ 140°F)
Storage Temp.
-20°C ~ 80°C (-4°F ~ 176°F)
Operating Humidity
5% ~ 90% Relative Humidity, Non-condensing
Weight
1.45lbs (0.65kg)
Power Requirement
+12V/+5V/5VSB/+3.3V/-12V
Power Mode
AT/ATX (Default Setting: ATX)
Dimension (L x W)
9.6″ x 9.6″ (243.84mm x 243.84mm)
