Description
Contact Capacity
Min. Current 100mA/repeatedly,Max. Current 30A/5 cycles
Temperature Setting Range (at no load)
50C ~ 150C in increments of 5C
ON-OFF Differential Temperature
(general)
30+-15K
Life Cycle(Resistive Load)
10A/125VAC 10,000 cycles
7A/250V AC 10,000 cycles
3A/48V DC 6,000 cycles
2.2A/48V DC 10,000 cycles
Safety Certification
UL, VDE, CSA, CQC, KC
Features
Snap Action
Automatic Reset
Superior Heat Response
PBT Resin Case with Epoxy Sealing
Moisture/Dust-Proof
Wire Customization Upon Request
IP(Ingress Protection): Solids 4, Liquids 5
Application
Electric Motors, Battery Chargers, Transformers,
Power Supplies, Heating Pads, Fluorescent Ballasts,
OA-Machines, Solenoids, LED Lighting, etc.
Tolerance
Indicated temperature 5C
Heat Endurance
Open Temp. +50/continuity, 200/1min
Manufacturer Part Number: ST-22W-90C-100L
Manufacturer: Electronic Components
