Description
SN74GTL2014PWR Texas Instruments Voltage Level Translator 4-bits 3.3V LVTTL to GTL Transceiver 14-TSSOP T/R RoHS
The SN74GTL2014 is a 4-channel translator to interface between 3.3-V LVTTL chip set I/O and Xeon processor GTL/GTL/GTL+ I/O.
Specifications
Manufacturer: Texas Instruments
Product Category: Translation – Voltage Levels
Type: LVTTL to GTL
Propagation Delay Time: 7 ns
Supply Voltage – Max: 3.6 V
Supply Voltage – Min: 3 V
Minimum Operating Temperature: – 40 C
Maximum Operating Temperature: + 85 C
Mounting Style: SMD/SMT
Package / Case: TSSOP-14
Series: SN74GTL2014
Packaging: Reel
Packaging: Cut Tape
Brand: Texas Instruments
Input Type: LVTTL
Logic Family: GTL
Number of Channels: 4 Channel
Operating Supply Current: 10 mA
Operating Temperature Range: – 40 C to + 85 C
Output Type: GTL
Product Type: Translation – Voltage Levels
Subcategory: Logic ICs
Unit Weight: 0.004949 oz
Manufacturer: Texas Instruments
MFG Part #: SN74GTL2014PWR
