Description
SPFI025.L Littelfuse POWR-GARD SPFI Fast Blow Solar (Photovoltaic) Cartridge Fuse 25A 1kVDC CE, UR Requires Holder
The Littelfuse SPXI solar fuse is designed to integrate into an in-line assembly within a wire harness. The fuse provides photovoltaic (PV) protection that meets UL 248-19 for photovoltaic applications. The SPXI can be electrically insulated by either overmolding or using heat-shrink.
Type of fuse fuse
Current rating 25A
Rated voltage 1kV DC
Fuse characteristics quick blow
Kind of fuse cylindrical
Fuse size 10.3×63.5mm
Mounting holders
Breaking capacity 20kA
Contact material copper alloy
Contact plating nickel plated
Conform to the norm CE
Breaking Capacity at Rated Voltage: 20kA
Package (Case): Cylindrical, Blade Terminals
Size (Dimension): 0.406″ Dia x 2.500″ L (10.31mm x 63.50mm)
Manufacturer Part Number: SPFI025.L
Manufacturer: Littelfuse Inc.
