Description
STM32F303RBT6 STMicroelectronics MCU 32-bit ARM Cortex M4 RISC 128KB Flash 2.5V/3.3V 64-Pin LQFP Tray RoHS
Specifications
Manufacturer:STMicroelectronics
Product Category:ARM Microcontrollers – MCU
Series:STM32F303RB
Mounting Style:SMD/SMT
Package / Case:LQFP-64
Core:ARM Cortex M4
Program Memory Size:128 kB
Data Bus Width:32 bit
ADC Resolution:12 bit
Maximum Clock Frequency:72 MHz
Number of I/Os:27 I/O
Data RAM Size:32 kB
Operating Supply Voltage:2 V to 3.6 V
Minimum Operating Temperature:- 40 C
Maximum Operating Temperature:+ 85 C
Packaging:Tray
Program Memory Type:Flash
Brand:STMicroelectronics
Data RAM Type:SRAM
Interface Type:CAN, I2C, I2S, SPI, UART, USART, USB
Moisture Sensitive:Yes
Number of ADC Channels:2 Channel
Number of Timers/Counters:10 Timer
Processor Series:ARM Cortex M
Product Type:ARM Microcontrollers – MCU
Factory Pack Quantity:960
Subcategory:Microcontrollers – MCU
Tradename:STM32
Unit Weight:0.012088 oz
The STM32F303xB/STM32F303xC family is based on the high-performance ARM Cortex -M4 32-bit RISC core with FPU operating at a frequency of up to 72 MHz, and embedding a floating point unit (FPU), a memory protection unit (MPU) and an embedded trace macrocell (ETM). The family incorporates high-speed embedded memories (up to 256 Kbytes of Flash memory, up to 40 Kbytes of SRAM) and an extensive range of enhanced I/Os and peripherals connected to two APB buses.The devices offer up to four fast 12-bit ADCs (5 Msps), seven comparators, four operational amplifiers, up to two DAC channels, a low-power RTC, up to five general-purpose 16-bit timers, one general-purpose 32-bit timer, and two timers dedicated to motor control.
Manufacturer: STMicroelectronics
MFG Part #: STM32F303RBT6
