Description
The 2N3439 and 2N3440 are silicon epitaxial planar NPN transistors in jedec TO-39 metal case designed for use in consumer and industrial line-operated applications.
STMicroelectronics – SGS 2N3440 Trans GP BJT NPN 250V 1A 3-Pin TO-39
Specifications
Product Category: Bipolar Transistors – BJT
Manufacturer: Central Semiconductor
Mounting Style: Through Hole
Package / Case: TO-39-3
Transistor Polarity: NPN
Configuration: Single
Collector- Emitter Voltage VCEO Max: 250 V
Collector- Base Voltage VCBO: 300 V
Emitter- Base Voltage VEBO: 7 V
Collector-Emitter Saturation Voltage: 0.5 V
Maximum DC Collector Current: 1 A
Gain Bandwidth Product fT: 15 MHz
Maximum Operating Temperature: + 150 C
Series: 2N3440
Continuous Collector Current: 0.45 A
DC Collector/Base Gain hfe Min: 40
Height: 6.6 mm
Length: 9.4 mm
Minimum Operating Temperature: – 65 C
Packaging: Bulk
Pd – Power Dissipation: 1000 mW
Factory Pack Quantity: 500
Width: 9.4 mm
Manufacturer:STMicroelectronics
Datasheet:STMicro/en.CD00000896.pdf
