Description
STWA48N60DM2 STMicroelectronics MOSFET N-channel 600 V, 0.065 Ohm typ 40 A MDmesh DM2 Power Through Hole TO-247 Long Leads RoHS
Specifications
Manufacturer: STMicroelectronics
Product Category: MOSFET
Technology: Si
Mounting Style: Through Hole
Package / Case: TO-247-3
Transistor Polarity: N-Channel
Number of Channels: 1 Channel
Vds – Drain-Source Breakdown Voltage: 600 V
Id – Continuous Drain Current: 40 A
Rds On – Drain-Source Resistance: 65 mOhms
Vgs – Gate-Source Voltage: – 25 V, + 25 V
Vgs th – Gate-Source Threshold Voltage: 3 V
Qg – Gate Charge: 70 nC
Minimum Operating Temperature: – 55 C
Maximum Operating Temperature: + 150 C
Pd – Power Dissipation: 300 W
Channel Mode: Enhancement
Tradename: MDmesh
Packaging: Tube
Brand: STMicroelectronics
Configuration: Single
Fall Time: 9.8 ns
Product Type: MOSFET
Rise Time: 27 ns
Series: STWA48N60DM2
Subcategory: MOSFETs
Transistor Type: 1 N-Channel
Typical Turn-Off Delay Time: 131 ns
Typical Turn-On Delay Time: 27 ns
Unit Weight: 0.211644 oz
