Description
P40133-1A Southwire TAPPAN® Shielded Cable Plenum CMP/CL3P 18 AWG PVC Jacket 2-Conductor Aluminum Foil Shielded White 1000 ft.
Construction
Conductor:Stranded bare copper per ASTM B8
Insulation:Low Smoke Polyvinyl Chloride (LS-PVC)
Shield:Aluminum foil shield with 24 AWG tinned drain wire
Rip Cord:Rip cord for ease of jacket removal
Jacket: White Low Smoke Polyvinyl Chloride (LS-PVC)
Remote Control, Signalling, and Power-Limited circuits per NEC Article 725 22AWG through 16 AWG also communication circuits per NEC Article 800. Security, sound and audio, speaker cable, public address, intercom, sound reinforcement, alarm and access control circuits and power-limited controls. Where routed in plenum spaces.
Specifications
Description – 18/2C STR BC OAS CMP/CL3P
AWG – 18
Number of Conductors – 2
Stranded / Solid – STR
BC/TD – BC
Shielded – OAS
Nom DIA (Inches) – 0.160
Weight (Lbs/Mft) – 20
Jacket Color – White
UL/NEC – CMP/CL3P
Compliance
Flame Test – NFPA 262 (Formerly UL 910 Steiner Tunnel)
Cable Type – CL3P. Also CMP where UL permits (Sizes 16 AWG and smaller.)
Voltage – 300V
Temperature – 75°C
QA – UL listed to UL 444 and UL 13 as applicable
