Description
TC74VHCT245AFT(E,K) TOSHIBA IC Bus XCVR Single 8-CH 3-ST 20-Pin TSSOP RoHS
Electrical Characteristics
| Characteristics | Symbol | Condition | Value | Unit |
|---|---|---|---|---|
| Output current (Min) | IO | VCC=4.5V | 8 | mA |
| Propagation delay time (Typ.) | tpd_tpz | VCC=5V | 4.9 | nsec |
| Supply Voltage (Max) | VCC | – | 5.5 | V |
| Supply Voltage (Min) | VCC | – | 4.5 | V |
Specifications
Technology:CMOS
Input Logic Level:TTL
Logical Function:Bus Transceiver
Mounting:Surface Mount
Number of Channels:8
Operating Temp Range:-40C to 85C
Output Type:3-State
Package Type:TSSOP
Pin Count:20
Polarity:Non-Inverting
Propagation Delay Time:16.5 ns
Number of Elements:1
Operating Temperature Classification:Industrial
Output Logic Level:CMOS
Logic Family:VHCT
Rad Hardened:No
Operating Supply Voltage (Typ):5 V
Operating Supply Voltage (Min):4.5 V
Operating Supply Voltage (Max):5.5 V
Manufacturer:Toshiba
Datasheet:Toshiba/TC74VHCT245AFT_datasheet_ja_20140301.pdf
