Description
TE Connectivity AMP 1-1776555-5^Connector 15 Position Wire to Board Terminal Block Vertical with Board 0.197″ (5.00mm) Through Hole
Product Attributes
Categories Connectors, Interconnects
Terminal Blocks – Wire to Board
Manufacturer TE Connectivity AMP Connectors
Series Buchanan
Packaging ? Bulk ?
Part Status Obsolete
Number of Levels 1
Positions Per Level 15
Pitch 0.197″ (5.00mm)
Mating Orientation Vertical with Board
Current 10A
Voltage 300V
Wire Gauge 14-22 AWG
Mounting Type Through Hole
Wire Termination Screw – Leaf Spring, Wire Guard
Features Interlocking (Side)
Color Blue
Operating Temperature -55C ~ 105C
Housing Material Polyamide (PA66), Nylon 6/6
Contact Material – Plating Brass – Copper Tin Plated
Clamp Material – Plating Steel, Stainless
Screw Material – Plating Steel, Galvanized – Chromate Plated
Torque – Screw 0.51 Nm (4.5 Lb-In)
Screw Thread M2.6
Manufacturer:TE Connectivity
Datasheet:ENG_SS_408-10012_B.pdf
