Description
TES 1-2421V Traco DC/DC converter 1V 1W Isolated Surface Mount, Voltage out 5V dc Isolated Module Output 5 VDC 100mA SMD 12 Pin RoHS
Specifications
Manufacturer: TRACO Power
Product Category: Isolated DC/DC Converters
Number of Outputs: 2 Output
Output Power: 1 W
Input Voltage, Nominal: 24 V
Output Voltage-Channel 1: 5 V
Output Current-Channel 1: 100 mA
Output Voltage-Channel 2: – 5 V
Output Current-Channel 2: 100 mA
Isolation Voltage: 3 kV
Minimum Operating Temperature: – 40 C
Maximum Operating Temperature: + 85 C
Mounting Style: SMD/SMT
Package / Case: SMD-12
Length: 16.3 mm
Width: 8 mm
Height: 8 mm
Industry: Industrial
Product: Isolated
Series: TES 1V
Application: Board Level Power Distribution, Telecom, Industrial Apllications
Input Voltage: 24 V
Packaging: Tube
Brand: TRACO Power
Moisture Sensitive: Yes
Product Type: Isolated DC-DC Converters
Factory Pack Quantity: 10
Subcategory: DC-DC Converter
Unit Weight: 0.070548 oz
The TES-1V series are miniature, 1W DC/DC-converters with high isolation in a SMD package. With a new package design these converters are qualified for the higher temperatures requested by lead-free reflow solder processes. With the small footprint, these converters are the ideal solution for board level power distribution, mainly for applications in the industrial- and telecom field. For automated SMD production lines the devices can be supplied in standard tape and reel package.
Manufacturer: Electronic Components
MFG Part #: TES-1-2421V
