Description
California Eastern Laboratories (CEL) THC63LVD1024 receiver is designed to support Dual Link transmission between Host and Flat Panel Display up to 1080p/60Hz, supporting varied I/O data mapping, suited to not only TV applications but also projector and security camera systems.
Features
LVDS to LVCMOS Conversion
5ch LVDS 2ports (Dual Link) input
?945Mbps/ch
?Wide LVDS input skew margin Max. ±650ps
LVCMOS Parallel 2ports output
?67bit/2pixel
?270Mpixel/sec. (Max. Clock Freq. 135MHz)
?TTL Clock output timing programmable
Data mapping selectable
Package?LQFP144
Power Supply?3.3V
Operating Temperature?-40 to 85?
Specifications
Manufacturer: CEL
Product Category: LVDS Interface IC
RoHS
Type: Deserializer
Number of Drivers: 70 Driver
Number of Receivers: 10 Receiver
Data Rate: 1.1 Gb/s
Input Type: LVDS
Output Type: CMOS, TTL
Supply Voltage – Max: 3.6 V
Supply Voltage – Min: 3 V
Minimum Operating Temperature: – 40 C
Maximum Operating Temperature: + 85 C
Mounting Style: SMD/SMT
Package / Case: LQFP-144
Packaging: Tray
Product: LVDS
Brand: CEL
Moisture Sensitive: Yes
Pd – Power Dissipation: 4.4 W
Product Type: LVDS Interface IC
Factory Pack Quantity: 600
Subcategory: Interface ICs
Manufacturer:Electronic Components
Datasheet:THC63LVD1024.pdf
