Description
TIBPAL22V10-20MJTB TI SPLD IMPACT-X Family 800 Gates 10 Macro Cells 33.3MHz 5V 24-Pin CDIP Tube
The is a programmable array logic device featuring high speed and functional equivalency when compared to presently available devices. They are implemented with the familiar sum-of-products (AND-OR) logic structure featuring the new concept “Programmable Output Logic Macrocell”. These IMPACT-X TM circuits combine the latest Advanced Low-Power Schottky technology with proven titaniumtungsten fuses to provide reliable, high-performance substitutes for conventional TTL logic. These devices contain to 22 inputs and 10 outputs. They incorporate the unique capability of defining and programming the architecture of each output on an individual basis. Outputs may be registered or nonregistered and inverting or noninverting as shown in the output logic macrocell diagram. The ten potential outputs are enabled through the use of individual product terms. Further advantages can be seen in the introduction of variable product term distribution. This technique allocates from to 16 logical product terms to each output for an average of 12 product terms per output. This variable allocation of terms allows far more complex functions to be implemented than in previously available devices.
Device System Gates 800
Minimum Operating Supply Voltage 4.5 V
Maximum Operating Supply Voltage 5.5 V
Screening Level Military
Typical Operating Supply Voltage 5 V
Mounting Through Hole
Lead Finish Tin/Lead
Speed Grade 20
Maximum Internal Frequency 33.3 MHz
Operating Temperature -55 to 125 °C
Maximum Number of User I/Os 10
Manufacturer Part Number: TIBPAL22V10-20MJTB
Manufacturer: Texas Instruments
