UPC7815AHF-AZ Renesas Electronics Fixed Positive Standard Regulator, 15VBIPolar, PSFM3
Part Category: Regulators
Mfr Package Description ISOLATED, PLASTIC, TO-220, SIP-3
REACH Compliant Yes
EU RoHS Compliant Yes
Status Discontinued
Regulator Type FIXED POSITIVE SINGLE OUTPUT STANDARD REGULATOR
Adjustability FIXED
Dropout Voltage1-Nom 1.8 V
Input Voltage Absolute-Max 35.0 V
Input Voltage-Min 17.5 V
Input Voltage-Max 30.0 V
specification
Output voltage 15 V
Output current Max 1A
Package type TO-220
Output type Fixed
Mounting type Through hole
Input voltage Min 17.5 V
Input voltage Max 30 V
The number of pins 3
Operating temperature Min -30C
Operating temperature Max + 85C
Number of outputs 1
polarity Positive
height 8.5 mm
width 4.5 mm
Standard dropout voltage @ current 1.8 V @ 1 A
Line regulation 45 mV
length 10.4 mm
Size 10.4 x 4.5 x 8.5 mm
Road regulation 190 mV
Manufacturer Part Number: UPC7815AHF-AZ
Manufacturer: Renesas
