Description
US TOYO FAN USTF120381152T AC Fan, 120 x 38 MM, 115 VAC, 1950 RPM, Terminal
Material
Frame – Aluminum Alloy, Painted Black Finish
Bearings – Dual Shielded Ball
Impeller – UL94V-0 Plastic (Reinforced)
Size: 4.69 in. sq x 1.5 in. thick (120mm sq x 38mm thick)
Weight: 19.4 oz (550g)
Airflow: 76 CFM
Performance data obtained with test chamber and methods in accordance with AMCA Standard 210-74
Acoustical Noise: 30 dB (A)
Acoustical measurements made at distance of 1.0 meter from fan intake. AC fans operating at 60 Hz line frequency. All measurements made on dB(A) scale
Termination: Terminals
Rotations per Minute: 1950
Operation Temperature: -10° to + 70° C
Storage Temperature: -40° to +70° C
Impedance Protection: All fans are designed and manufactured to prevent “burn-out” failure caused by restriction of rotating parts
Insulation Resistance: 100,000 Ohm min @ 500 VDC
Dielectric Strength: 500 VAC for 1 minute
Insulation: Class A
Safety: Impedance Protected
Safety Approvals: UL, CSA, and CE
Approved fans are listed as follows: UL No. E106227, CSA No. 073720 and VDE No. 16599
Approved for use on AC voltages at 60 Hz and 50 Hz frequencies
Operating Voltage: 115VAC (75VAC min)
Supplier:
U.S. TOYO Fan
Part No:
USTF120381152T
RoHS:
Yes
HTS:
8414596090
COO:
CN
ECCN:
EAR99
Warning Click to see warning.
California Prop 65
Dimension:
119 x 119 x 38 mm
Bearings:
Ball
CFM VAL:
76
Operating Temperature:
-40 to 70 °C
Housing Material:
Aluminum Alloy
Power Rating:
7 W
Special Features:
None
Category:
AC Fan
Operating Frequency:
60 Hz
Fan Rotation:
Clockwise
Noise Level:
30 dB
Nominal Speed:
1950 r/min
Operating Input Voltage Range:
N/A
Mounting:
Flange Mount
Voltage Rating:
115 V
Line Current:
0.1 A
Termination:
Terminals
Maximum Airflow:
76 CFM
Family:
USTF12038
Unit of Measure:
Per Each
Manufacturer Part Number: USTF120381152T
Manufacturer: US Toyo Fan
